All ProductsFX18

Features

- 0.8mm Pitch
- Variations :Coplanar / Vertical / Stacking
- Number of Contacts : 40 / 60 / 80 / 100 / 120/ 140
- Multi functional contact (MF contact) as;
1. ground contact to enhance grounding.
2. power supply contacts up to 12 A to reduce required pin counts.
3. 3-step sequential contacts for grounding and detection.
- Effective mating length of signal contact:2.0 mm.
(MF contact A: 2.5 mm / MF contact B: 1.5 mm)
- Pin through hole mounting MF contacts increase strength against wrenching.
- Large mating guide for easy mating.

FunctionMAX special page

FunctionMAX is the best selection for board-to-board connectors Superior performance is ensured in diverse environments.

Specifications

Connector Type Plug, Receptacle, Interposer
Transmission Rate 10 Gbps
Contact Pitch 0.8 mm
Mounting Pitch 0.8 mm
Mated Height 10 to 45 [10, 15, 20, 25, 30, 35, 40, 45] mm
Number of Positions 40, 100, 120, 140, 60, 80, 160, 180
Remarks on Number of Positions 4 Power contacts
Mating/Unmating Cycles 500
Mounting Style SMT
Connector Orientation Straight, Right angle
Contact Plating Gold
Rated Current 0.5 A
Rated Voltage (AC) AC 100 V
Operating Temperature (Max.) 85 ℃
Operating Temperature (Min.) -55 ℃
Catalog Product Series Catalog DOWNLOAD
Data Sheet Simulation Model(IBIS)
DOWNLOAD
Simulation Model (Touchstone)
DOWNLOAD
Signal Integrity Report
DOWNLOAD
Assembly Information Product Guidelines
DOWNLOAD

*I need help with a product or information

Products

PART NUMBER CONFIGURATION

Number of Positions   pos. Connector Type

Connector Orientation

Mated Height

  mm

Positioning Boss



Part No.

Drawing

Number of Positions

Connector Height

Connector Orientation

Mated Height (Min.)

Mated Height (Max.)

Mated Height

Positioning Boss

100
9.5 mm
Right angle
No
100
8.65 mm
Straight
10 mm
35 mm
10,15,20,25,30,35 mm
No
100
18.65 mm
Straight
20 mm
45 mm
20,25,30,35,40,45 mm
No
100
19.7 mm
25 mm
45 mm
25,30,35,40,45 mm
No
100
9.5 mm
Right angle
No
100
7 mm
Straight
10 mm
35 mm
10,20,25,35 mm
No
100
11.75 mm
Straight
15 mm
40 mm
15,25,30,40 mm
No
100
16.75 mm
Straight
20 mm
45 mm
20,30,35,45 mm
No
120
9.5 mm
Right angle
No
120
8.65 mm
Straight
10 mm
35 mm
10,15,20,25,30,35 mm
No
120
18.65 mm
Straight
20 mm
45 mm
20,25,30,35,40,45 mm
No
120
19.7 mm
25 mm
45 mm
25,30,35,40,45 mm
No
120
9.5 mm
Right angle
No
120
7 mm
Straight
10 mm
35 mm
10,20,25,35 mm
No
120
11.75 mm
Straight
15 mm
40 mm
15,25,30,40 mm
No
120
16.75 mm
Straight
20 mm
45 mm
20,30,35,45 mm
No
140
9.5 mm
Right angle
No
    140
    8.65 mm
    Straight
    10 mm
    35 mm
    10,15,20,25,30,35 mm
    No
    140
    18.65 mm
    Straight
    20 mm
    45 mm
    20,25,30,35,40,45 mm
    No
