FX20 Series

Features

0.5 mm Pitch, Board to Board Connector with Floating Structure

1. 0.5 mm pitch
2. Connection type: Right angle / Vertical
3. Pin counts : 20, 40, 60, 80, 100, 120 and 140
4. Floating range: ± 0.6 to 0.8 mm in the X direction and +/- 0.6 mm in the Y direction
5. A double beam contact structure produces a highly reliable contact (Refer to the figure on the right)
6. Current capacity: 0.5 A per pin
7. Effective mating length of 1.5 mm
8. No conductive trace surface is not specified
9. Contains the vacuum pick up area needed to allow automatic mounting
10.Self-aligning and self-guiding structure

FunctionMAX special page

FunctionMAX is the best selection for board-to-board connectors Superior performance is ensured in diverse environments.

Specifications

Connector Type Receptacle, Header
Contact Pitch 0.5 mm
Mounting Pitch 0.5 mm
Mated Height 15 to 30 [15, 20, 25, 30] mm
Number of Positions 20, 40, 60, 80, 100, 120, 140
Floating Design Yes
Mating/Unmating Cycles 50
Mounting Style SMT
Connector Orientation Straight, Right angle
Contact Plating Gold
Rated Current 0.5 A
Rated Voltage (AC) AC 50 V
Operating Temperature (Max.) 85 ℃
Operating Temperature (Min.) -55, -15 ℃

Component PartsFUNCTION CHART

Catalog Product Series Catalog DOWNLOAD
Data Sheet Simulation Model(IBIS)
DOWNLOAD
Simulation Model (Touchstone)
DOWNLOAD
Signal Integrity Report
DOWNLOAD

*I need help with a product or information

Products

PART NUMBER CONFIGURATION

Number of Positions   pos. Connector Type

Connector Orientation

Mated Height

  mm

Positioning Boss



Part No.

Drawing

inventory

Number of Positions

Connector Height

Connector Orientation

Mated Height (Min.)

Mated Height (Max.)

Mated Height

Positioning Boss

100
13.2 mm
Straight
15 mm
25 mm
15,25 mm
100
13.2 mm
Straight
15 mm
25 mm
15,25 mm
100
18.2 mm
Straight
20 mm
30 mm
20,30 mm
100
18.2 mm
Straight
20 mm
30 mm
20,30 mm
100
7.15 mm
Right angle
100
8.3 mm
Straight
15 mm
20 mm
15,20 mm
100
18.3 mm
Straight
25 mm
30 mm
25,30 mm
120
13.2 mm
Straight
15 mm
25 mm
15,25 mm
120
13.2 mm
Straight
15 mm
25 mm
15,25 mm
    120
    13.2 mm
    15 mm
    25 mm
    15,25 mm
    120
    18.2 mm
    Straight
    20 mm
    30 mm
    20,30 mm
    120
    18.2 mm
    Straight
    20 mm
    30 mm
    20,30 mm
    120
    7.15 mm
    Right angle
    120
    8.3 mm
    Straight
    15 mm
    20 mm
    15,20 mm
      120
      8.3 mm
      Straight
      15 mm
      20 mm
      15,20 mm
      120
      18.3 mm
      Straight
      15 mm
      30 mm
      15,20,30 mm
        120
        18.3 mm
        15 mm
        30 mm
        15,20,30 mm
        140
        13.2 mm
        Straight
        15 mm
        25 mm
        15,25 mm
        140
        13.2 mm
        Straight
        15 mm
        25 mm
        15,25 mm
        140
        13.2 mm
        15 mm
        25 mm
        15,25 mm
