All ProductsDF62

Features

2 x 2.2 mm Pitch, Wire-to-Wire Connectors for Small Spaces

1. The slim, sleek design and smooth contour combine to complete connections in tight spaces.
2. Secure lock mechanism
3. Reliable contact structure
4. Robust contact structure
5. Multiple variations available
6. Applicator sharing

Specifications

Connector Type Contact, Socket, Header, In-line plug
Number of Positions 13, 24, 2, 3, 4, 5, 6, 7
Number of Rows (Interface) 4, 5, 1, 2, 3
Mounting Pitch 2.2 mm
Contact Pitch 2.2 mm
Rated Current 2, 3, 4, 2.5, 1 A
Rated Voltage (AC) AC 250 V
Rated Voltage (DC) DC 250 V
Mating/Unmating Cycles 30, 50
Mounting Style THT
Panel Mounting Style Snap-in
Contact Plating Gold, Tin
Wire Termination Method Crimping
Recommended Wire Type Discrete wire
Recommended Min. Wire Size (AWG) AWG 28, 22, 30
Recommended Max. Wire Size (AWG) AWG 24
Operating Temperature (Max.) 105 ℃
Operating Temperature (Min.) -35, -40 ℃
Glow Wire Compliant No, Yes
Catalog Product Series Catalog DOWNLOAD
Assembly Information Cable Assembly Instruction DOWNLOAD
