BK13 Series Recommended

0.35mm Pitch, 0.6mm Stacking Height, 1.9mm Width, Low-Profile Hybrid FPC-to-Board Connector Supporting 5A


Features

0.35mm Pitch, 0.6mm Stacking Height, 1.9mm Width, Low-Profile Hybrid FPC-to-Board Connector Supporting 5A

1. High Power Supply Capacity and Space-saving Design
2. Robust Design
3. Enhanced PCB Peeling Strength
4. High Contact Reliability
5. Superior Mating
6. Halogen-Free

CATALOG
CONTACT US
Product Numbers by Series

Video list



Select Map of Narrow Pitch Connectors

This page summarizes the board-to-FPC / narrow-pitch connectors.
On this page, you can choose the best connector for use, size and current rating.

  • Connector Type
  • Plug, Receptacle
  • Parts
  • Industry Standard
  • Safety Standards
  • Performance Characteristics
  • Transmission Rate
  • Contact Pitch
  • 0.35 mm
  • Mounting Pitch
  • Tab Width (mm)
  • Applicable FPC Cable Thickness (mm)
  • Mated Height (Min.)
  • 0.6 mm
  • Mated Height (Max.)
  • 0.6 mm
  • Mated Height (STEP)
  • 0.6 mm
  • Number of Positions
  • 6, 10, 12, 16, 24, 32, 40, 50, 60
  • Remarks on Number of Positions
  • Floating Design
  • Floating Range(XY)(mm)
  • Effective Mating Length(Z)(mm)
  • Mating/Unmating Cycles
  • 30
  • Mounting Style
  • SMT
  • Connector Orientation
  • Contact Plating
  • Gold
  • Rated Current
  • 5.0 A
  • Rated Current other
  • 0.3 A
  • Rated Voltage (AC)
  • AC 50.0 V
  • Rated Voltage (AC) other
  • AC 50.0 V
  • Rated Voltage (DC)
  • DC 50.0 V
  • Rated Voltage (DC) other
  • DC 50.0 V
  • Operating Temperature Max.
  • 85 ℃
  • Operating Temperature Min.
  • -55 ℃
  • Connector Type Details

Major Applications/Product Categories

Board-to-Board, Board-to-FPC
Power
Smart Watches
Drone
Drone
Smart Glass
Tablet PCs
Electronic Cigarette
Smartphones

List of Connectors (Specification Sheet, 2D drawings, 3D models, Distributor inventory)

PART NUMBER CONFIGURATION

In cases where the application will demand a high level of reliability, such as automotive, please contact a company representative for further information.

Catalog

Data Sheet
