All ProductsDF33C

Features

3.3 mm Pitch Small Size Connectors for Internal Power Source

1. 5 Amps capacity
2. Secure lock mechanism
3. Incorrect mating prevention
4. Accurate board placement
5. Supports resin sealing
6. Short circuit prevention
7. Excellent contact retention
8. Prevents solder cracking
9. Easy mating operation
10. Glow Wire compliance (Compliant with IEC 60695-2-11)

EnerBee special page

EnerBee offers a positive lock mechanism to meet various requirement of industrial power supply and power sources.

Specifications

Connector Type Socket, Header, Accessory
Number of Positions 4, 10, 12, 2, 3, 5, 6, 8
Number of Rows (Interface) 2, 1
Mounting Pitch 3.3 mm
Contact Pitch 3.3 mm
Rated Current 5 A
Rated Voltage (AC) AC 500 V
Rated Voltage (DC) DC 500 V
Mating/Unmating Cycles 30
Mounting Style THT
Connector Orientation Straight
Mounting Side Standard on-Board
Contact Plating Tin
Wire Termination Method Crimping
Recommended Wire Type Discrete wire
Operating Temperature (Max.) 85 ℃
Operating Temperature (Min.) -35 ℃
Glow Wire Compliant Yes

Component PartsFUNCTION CHART

Catalog Product Series Catalog DOWNLOAD
Assembly Information Cable Assembly Instruction DOWNLOAD
