All ProductsDF63

Features

15A 3.96mm pitch Wire-to-Board Connectors for Internal Power Supply

1. Rated for up to 15A
2. Secure mating and clear tactile click
3. Prevents incomplete insertion of the crimp contact
4. Prevents incorrect mating
5. Reverse mounting prevention to PCB
6. Molded lance design
7. Short-circuit prevention
8. Suitable for potting
9. Solder crack prevention
10. Glow Wire compliance (Compliant with IEC 60695-2-11)

Specifications

Connector Type Contact, Socket, Header, In-line plug
Cable Assembly No
Safety Standards UL, C-UL/CSA, TÜV
Number of Positions 1, 2, 3, 4, 5, 6
Number of Rows (Interface) 1
Mounting Pitch 3.96, 7.92 mm
Contact Pitch 3.96, 7.92 mm
Rated Current 10, 15, 11, 14, 13, 12 A
Rated Voltage (AC) AC 630 V
Rated Voltage (DC) DC 630 V
Mating/Unmating Cycles 30, 50
Mounting Style THT
Connector Orientation Straight, Right angle
Mounting Side Standard on-Board
Panel Mounting Style Snap-in, DIN rail
Contact Plating Gold, Tin
Wire Termination Method Crimping
Recommended Wire Type Discrete wire
Recommended Min. Wire Size (AWG) AWG 22
Recommended Max. Wire Size (AWG) AWG 16
Operating Temperature (Max.) 105 ℃
Operating Temperature (Min.) -55 ℃
Glow Wire Compliant Yes
Catalog Product Series Catalog DOWNLOAD
Assembly Information Cable Assembly Instruction DOWNLOAD
