FX23L Series

Features

0.5 mm pitch, Power/Signal Hybrid, Low-Profile Floating Board to Board Connectors for High Speed Transmission

1. +/- 0.6 mm max. floating in XY directions
2. High speed transmission up to 8 Gbps
3. 2 power contacts on each side of connector housing (3 Amps/pin)
4. Signal contact rated up to 0.5 Amps/pin
5. Low-profile parallel connection
(Stacking Height: 8 m, 10 mm, 12 mm)
6. +/- 1.2 mm self-alignment structure for easy mating
7. RoHS compliant

FunctionMAX special page

FunctionMAX is the best selection for board-to-board connectors Superior performance is ensured in diverse environments.

Specifications

Connector Type Receptacle, Header
Transmission Rate 8 Gbps
Contact Pitch 0.5 mm
Mounting Pitch 0.5 mm
Mated Height 8 to 12 [8, 10, 12] mm
Number of Positions 20, 40, 60, 80, 100, 120
Floating Design Yes
Mating/Unmating Cycles 100
Mounting Style SMT
Connector Orientation Straight
Contact Plating Gold
Rated Current 0.5 A
Rated Voltage (AC) AC 50 V
Rated Voltage (DC) DC 50 V
Operating Temperature (Max.) 105 ℃
Operating Temperature (Min.) -55 ℃

Component PartsFUNCTION CHART

Catalog Product Series Catalog DOWNLOAD

*I need help with a product or information

Products

PART NUMBER CONFIGURATION

Number of Positions   pos. Connector Type

Connector Orientation

Mated Height

  mm

Positioning Boss



Part No.

Drawing

inventory

Number of Positions

Connector Height

Connector Orientation

Mated Height (Min.)

Mated Height (Max.)

Mated Height

Positioning Boss

100
8.85 mm
Straight
10 mm
10 mm
10 mm
No
100
10.85 mm
Straight
12 mm
12 mm
12 mm
No
100
6.85 mm
Straight
8 mm
8 mm
8 mm
No
100
5.8 mm
Straight
8 mm
12 mm
8,10,12 mm
No
120
8.85 mm
Straight
10 mm
10 mm
10 mm
No
120
10.85 mm
Straight
12 mm
12 mm
12 mm
No
120
6.85 mm
Straight
8 mm
8 mm
8 mm
No
120
5.8 mm
Straight
8 mm
12 mm
8,10,12 mm
No
20
8.85 mm
Straight
10 mm
10 mm
10 mm
No
20
10.85 mm
Straight
12 mm
12 mm
12 mm
No
20
10.85 mm
Straight
12 mm
12 mm
12 mm
No
20
6.85 mm
Straight
8 mm
8 mm
8 mm
No
20
5.8 mm
Straight
8 mm
12 mm
8,10,12 mm
No
20
5.8 mm
Straight
8 mm
12 mm
8,10,12 mm
No
40
8.85 mm
Straight
10 mm
10 mm
10 mm
No
40
10.85 mm
Straight
12 mm
12 mm
12 mm
No
40
6.85 mm
Straight
8 mm
8 mm
8 mm
No
40
5.8 mm
Straight
8 mm
12 mm
8,10,12 mm
No
60
8.85 mm
Straight
10 mm
10 mm
10 mm
No
60
10.85 mm
Straight
12 mm
12 mm
12 mm
No
