13-25 A Compatible, Position Misalignment Absorption Type Power Supply Connector for PCB Connections

1. Contact Pitch: 3.81 mm
2. Current Capacity: 13~25 A/pin
3. Connection Type:Coplanar / Vertical / Parallel
4. Number of Pos.: 2 / 3 / 4 / 5 Pos.
5. Position Misalignment Absorption Movable Amount: +/-0.3 mm
6. Effective Mating Length: 2 mm
7. Multi-point Contact Structure
8. Low Insertion / Extraction Force
9. Robustness
10. Large Guide Form Leads Superior Mating Ability
11. Protected structure
12. UL, C-UL and TUV certifications have been achieved.

FunctionMAX special page

FunctionMAX is the best selection for board-to-board connectors Superior performance is ensured in diverse environments.

Specifications

Connector Type Receptacle, Header
Contact Pitch 3.81, 7.62 mm
Mounting Pitch 3.81, 7.62 mm
Mated Height 20 to 30 [20, 25, 30] mm
Number of Positions 2, 3, 4, 5
Mating/Unmating Cycles 100
Mounting Style THT
Connector Orientation Straight, Right angle
Contact Plating Gold
Rated Current 23, 25, 22, 24, 20 A
Rated Voltage (AC) AC 250, 600 V
Rated Voltage (DC) DC 250, 600 V
Operating Temperature (Max.) 105 ℃
Operating Temperature (Min.) -55 ℃
Catalog Product Series Catalog DOWNLOAD
Data Sheet Simulation Model(IBIS)
DOWNLOAD

*I need help with a product or information

Products

PART NUMBER CONFIGURATION

Number of Positions   pos. Connection Style

Connector Orientation

Mated Height

  mm

Positioning Boss



Part No.

Drawing

Number of Positions

Connector Height

Connector Orientation

Mated Height (Min.)

Mated Height (Max.)

Mated Height

Positioning Boss

2
11 mm
Right angle
Yes
2
13 mm
Straight
20 mm
20 mm
20 mm
Yes
2
18 mm
Straight
25 mm
25 mm
25 mm
Yes
2
23 mm
Straight
30 mm
30 mm
30 mm
Yes
2
19 mm
Right angle
Yes
2
13 mm
Straight
20 mm
20 mm
20 mm
Yes
2
18 mm
Straight
25 mm
25 mm
25 mm
Yes
2
23 mm
Straight
30 mm
30 mm
30 mm
Yes
2
11 mm
Right angle
Yes
2
16.3 mm
Straight
20 mm
30 mm
20,25,30 mm
Yes
2
11 mm
Right angle
Yes
2
16.3 mm
Straight
20 mm
20 mm
20 mm
Yes
3
11 mm
Right angle
Yes
3
13 mm
Straight
20 mm
20 mm
20 mm
Yes
3
18 mm
Straight
25 mm
25 mm
25 mm
Yes
3
23 mm
Straight
30 mm
30 mm
30 mm
Yes
3
11 mm
Right angle
Yes
3
13 mm
Straight
20 mm
20 mm
20 mm
Yes
3
18 mm
Straight
25 mm
25 mm
25 mm
Yes
3
23 mm
Straight
30 mm
30 mm
30 mm
Yes
