RM Series
Multi-contact Compact Circular Connectors
Features
Multi-contact Compact Circular Connectors
1. 5 shell sizes (12, 15, 21, 24, and 31)
2. 16 kinds of contacts (2, 3, 4, 5, 6, 7, 8, 10, 12, 15, 20, 31, and 40)
3. Water proof types are available in special series.(RM-W Series)
4. Various lock mechanism (Thread coupling, Bayonet sleeve, and Quick detachable)
5. Various kinds of accessories are available.
Specifications
- Connector Type
- Plug, Receptacle, Jack, Contact, Others
- Parts
- Cap, Flange, Strain releaf
- Generic Type
- Industry Standard
- Safety Standards
- Performance Characteristics
- Rated Current
- 5.0, 10.0 A
- Rated Current other
- Rated Voltage (AC)
- AC 350.0, 500.0 V
- Rated Voltage (AC) other
- Rated Voltage (DC)
- DC 490.0, 700.0 V
- Rated Voltage (DC) other
- Number of Positions
- 3, 4, 6, 7, 10, 12, 15, 20, 31
- Remarks on Number of Positions
- Shell Size (mm)
- 12, 15, 21, 31, 24 mm
- Operating Temperature Max.
- 85 ℃
- Operating Temperature Min.
- -25 ℃
- Mounting direction
- Floating Range(XY)(mm)
- Effective Mating Length(Z)(mm)
- Water Resistance
- Contact Resistance
- 2.0, 4.0 mΩ Max.
- Withstanding Voltage
- 1000, 1500 V Max.
- Locking Style
- Screw, Bayonet, Push-on Bayonet
- Wire Termination Method
- Soldering, Crimping
- Cable Outer Diameter
- 6.0, 8.0, 9.0, 11.0, 15.0, 19.0 mm
- Mating/Unmating Cycles
- 1000, 2000
- Finger Protection
- No
- Metal Shields
- No
- Mounting Style
- THT
- Contact Plating
- Silver
- Salt Spray Test Duration (Corrosion Resistance)
- Shell Material
- Metal, Rubber
- Finish on Shell
- Nickel, Chrome
- Connector Type Details
- Accessory
List of Connectors (Specification Sheet, 2D drawings, 3D models, Distributor inventory)
Document
In cases where the application will demand a high level of reliability, such as automotive, please contact a company representative for further information.
