DF14 Series


1.25 mm Pitch Super Low profile Crimping Connector

1. Super Low Profile (Board mounting height: 2.5mm)
2. Correspond to Automatic Mounting
3. Four Wall Type Without Friction to Board by Socket

SignalBee special page

SignalBee, a sister brand to our power cable brand EnerBee, is your solution for signal cable connector.


Connector Type Contact, Socket, Header, Others
Cable Assembly No, Yes
Number of Positions 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 25, 30
Number of Rows (Interface) 1
Mounting Pitch 1.25 mm
Contact Pitch 1.25 mm
Rated Current 1 A
Rated Voltage (AC) AC 150 V
Mating/Unmating Cycles 30, 50
Mounting Style SMT
Connector Orientation Straight, Right angle
Mounting Side Standard on-Board, Standard off-set
Contact Plating Gold, Tin, Tin-Copper
Wire Termination Method Crimping
Recommended Wire Type Discrete wire
Recommended Min. Wire Size (AWG) AWG 28, 32
Recommended Max. Wire Size (AWG) AWG 26, 30
Operating Temperature (Max.) 85 ℃
Operating Temperature (Min.) -35 ℃
Glow Wire Compliant No
