LF Series Recommended

Shielded Small Waterproof Connector


Features

Shielded Small Waterproof Connector

1.  Small, Robust Design
2.  Bayonet Lock
3.  Waterproof : IPX7/IPX8 Compliant
4.  Easy Shielding Termination
5.  Easy Assembly
6.  Wide Variety of Configurations
7.  High Speed Transmission

　 Cat.5e (1Gbps) and Cat.6A (10Gbps) High-speed Ethernet support
8.  Suited for Long-Term Outdoor Use
9.  Safety Standard Certified

10. RoHS2 Compliant

CATALOG
CONTACT US
Product Numbers by Series

Video list



Related Products: HR10 Series

,

HR12 Series

Shielded Compact Waterproof Connector LF Series special page

Rugged & space-saving metal shell connecters sealed to IPX7&X8 for water-proof are designed to withstand harsh industrial environments.

Interface Connectors for Industrial Ethernet special page

Hirose Electric offers an extensive lineup of interface connectors for industrial Ethernet.

  • Connector Type
  • Plug, Receptacle, Jack, Others
  • Parts
  • Flange, Cap
  • Generic Type
  • Industry Standard
  • Safety Standards
  • UL, C-UL/CSA, TÜV
  • Performance Characteristics
  • CAT5e, CAT6A
  • Rated Current
  • 2.0, 4.0, 5.0, 10.0 A
  • Rated Current other
  • Rated Voltage (AC)
  • AC 30.0, 50.0, 60.0, 125.0 V
  • Rated Voltage (AC) other
  • Rated Voltage (DC)
  • DC 42.0, 60.0, 125.0, 175.0 V
  • Rated Voltage (DC) other
  • Number of Positions
  • 3, 4, 6, 8, 11, 12, 20
  • Remarks on Number of Positions
  • Hybrid 11pos. : Power 4pos. 10A, Signal 7pos. 2A, Hybrid 6pos. : Power 2pos. 4A, Signal 4pos. 1A
  • Shell Size (mm)
  • 7, 10, 13 mm
  • Operating Temperature Max.
  • 85 ℃
  • Operating Temperature Min.
  • -25 ℃
  • Mounting direction
  • Floating Range(XY)(mm)
  • Effective Mating Length(Z)(mm)
  • Water Resistance
  • IPX7, IP X8
  • Contact Resistance
  • Withstanding Voltage
  • 300, 1000, 1250 V Max.
  • Locking Style
  • Friction, Screw, Bayonet
  • Wire Termination Method
  • Soldering, Crimping
  • Cable Outer Diameter
  • 5.0, 6.5, 6.9, 7.3, 8.7 mm
  • Mating/Unmating Cycles
  • 1000
  • Finger Protection
  • No
  • Metal Shields
  • No, Yes
  • Mounting Style
  • THT
  • Contact Plating
  • Gold
  • Salt Spray Test Duration (Corrosion Resistance)
  • 48, 500 h
  • Shell Material
  • Metal
  • Finish on Shell
  • Nickel, Chrome
  • Connector Type Details
  • Accessory

Major Applications/Product Categories

I/O Connectors
Power Connectors
Sealed connector
Wire-to-Wire
Industrial Robots
Machine Tools/Semiconductor Manufacturing Equipment/Mounters/Production Line Equipment
Motors
Street Lighting/Tunnel Lighting
AGV / AMR
Industrial Robots
Service Robots
Patient Care Equipment
EV Charger
Industrial Sensors
LED Lighting
Service Robot
CNCs/PLCs
Stationary Storage Batteries
Base Transmission Stations
Motor Drives
Standard Products

List of Connectors (Specification Sheet, 2D drawings, 3D models, Distributor inventory)

PART NUMBER CONFIGURATION

In cases where the application will demand a high level of reliability, such as automotive, please contact a company representative for further information.
