DF1E Series

Features

[SignalBee]
2.5mm Pitch Connector for Full Lock and Discrete Wire Connection

1. Full Lock Function Added
2. Increase in Crimping Contact Fixation Force and Semi-insertion Prevention
3. Mold Lance Adopted
4. Mis-insertion Prevention
5. Means to Prevent Solder Crack
6. Correspond to Potting
7. Production Facility Cost Reduction
8. Various Applications
9. Listed by UL, C-UL

SignalBee special page

SignalBee, a sister brand to our power cable brand EnerBee, is your solution for signal cable connector.

Specifications

Connector Type Contact, Socket, Header, In-line plug, Accessory
Industry Standard JIS, IEC
Number of Positions 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15
Number of Rows (Interface) 1
Mounting Pitch 2.5, 3 mm
Contact Pitch 2.5 mm
Rated Current 3 A
Rated Voltage (AC) AC 250 V
Rated Voltage (DC) DC 250 V
Mating/Unmating Cycles 30, 50
Mounting Style THT
Connector Orientation Straight, Right angle
Mounting Side Standard on-Board
Panel Mounting Style Snap-in
Contact Plating Gold, Tin
Wire Termination Method Crimping
Recommended Wire Type Discrete wire
Recommended Min. Wire Size (AWG) AWG 22, 28
Recommended Max. Wire Size (AWG) AWG 20, 24
Operating Temperature (Max.) 85 ℃
Operating Temperature (Min.) -35 ℃
Glow Wire Compliant No, Yes
