DF3 Series

Features

[SignalBee]
2 mm Pitch Connector for Discrete Wire Connection (Product approved by UL CSA Standard)

1. Correspond to Board Design in Wide Variation
Crimp Socket
Receptacle
Pin Header
In-line Plug
2. UL, CSA Certified

SignalBee special page

SignalBee, a sister brand to our power cable brand EnerBee, is your solution for signal cable connector.

Specifications

Connector Type Adapter, Contact, Socket, Header, In-line plug, Short pin, Others
Cable Assembly No, Yes
Industry Standard JIS, IEC
Safety Standards UL, C-UL/CSA
Number of Positions 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15
Number of Rows (Interface) 1
Mounting Pitch 2 mm
Contact Pitch 2 mm
Rated Current 3 A
Rated Voltage (AC) AC 250 V
Rated Voltage (DC) DC 250 V
Mating/Unmating Cycles 30, 50
Mounting Style SMT, THT
Connector Orientation Straight, Right angle
Mounting Side Standard on-Board
Panel Mounting Style Screw, Snap-in
Contact Plating Gold, Tin
Wire Termination Method Crimping
Recommended Wire Type Discrete wire
Recommended Min. Wire Size (AWG) AWG 22, 24, 28
Recommended Max. Wire Size (AWG) AWG 22, 24, 28
Operating Temperature (Max.) 85, 105 ℃
Operating Temperature (Min.) -55, -30 ℃
Glow Wire Compliant No
