DF51 Series Recommended

[SignalBee™] 2mm Pitch, Positive Lock Wire-to-Board Connector (UL,C-UL Listed)


Features

[SignalBee™]

2mm Pitch, Positive Lock, Wire-to-Board Connector (UL, C-UL Standard Certified Product)

1. Positive lock provides clear tactile click and secures reliable connection.
2. Wide variation
3. Secure Side-locking design
4. Prevents incorrect mating
5. Uses the same contacts and crimping tools as DF11 Series
6. Suitable for potting
7. Branch Adapter
8. UL, C-UL Certified

SignalBee special page

SignalBee, a sister brand to our power cable brand EnerBee, is your solution for signal cable connector.

Specifications

FUNCTION CHART
  • Connector Type
  • Adapter, Socket, Header, In-line plug
  • Parts
  • Cable Assembly
  • No
  • Industry Standard
  • Safety Standards
  • UL, C-UL/CSA
  • Number of Positions
  • 2, 3, 4, 5, 6, 7, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 28, 30
  • Number of Rows (Interface)
  • 1, 2
  • Mounting Pitch
  • 2.0 mm
  • Contact Pitch
  • 2.0 mm
  • Connector Length
  • 10.8, 11.1, 12.8, 13.1, 14.8, 15.0, 15.1, 16.2, 16.4, 16.8, 17.0, 17.1, 17.5, 18.2, 18.4, 18.8, 19.0, 19.1, 19.5, 20.2, 20.4, 20.8, 21.0, 21.1, 21.5, 22.2, 22.4, 23.0, 23.1, 23.5, 24.2, 24.4, 25.0, 25.1, 25.5, 26.2, 26.4, 27.0, 27.1, 28.4, 29.0, 29.1, 30.4, 31.0, 31.1, 32.4, 33.0, 33.1, 34.4, 35.0, 35.1, 36.4, 37.0, 37.1, 38.4, 39.0, 40.4, 41.0, 42.4 mm
  • Connector Width
  • 4.4, 5.25, 5.4, 7.2, 7.3, 8.4, 10.14, 11.9, 12.0 mm
  • Connector Height
  • 4.5, 7.3, 8.4, 10.15, 10.7, 15.15, 16.4 mm
  • Mounting Style
  • THT
  • Mounting Side
  • Standard on-Board
  • PCB Stabilizing Feature
  • Soldering
  • Staggered Lead
  • No
  • Recommended PCB Thickness
  • 1.6 mm Max.
  • Connector Orientation
  • Straight, Right angle
  • Mating/Unmating Cycles
  • 30, 50
  • Contact Plating
  • Gold, Tin
  • Plating Thickness
  • Housing Color
  • Black
  • Wire Termination Method
  • Crimping
  • Recommended Wire Type
  • Discrete wire
  • Recommended Min. Wire Size (AWG)
  • 28, 30
  • Recommended Max. Wire Size (AWG)
  • 22, 24
  • Recommended Min. Wire Size (mm²)
  • Recommended Max. Wire Size (mm²)
  • Operating Temperature Max.
  • 105 ℃
  • Operating Temperature Min.
  • -55 ℃
  • Panel Mounting Style

In cases where the application will demand a high level of reliability, such as automotive, please contact a company representative for further information.
