DF63W Series Recommended

[EnerBee™] 3.96mm Pitch Compact Waterproof for Internal Power Supplies


Features

[EnerBee™]

3.96mm pitch compact waterproof connectors for internal power supplies

1. Max current of 14A
2. Compact shape designed for wiring through narrow areas
3. IP67 Rated
4. Simplified wire insertion
5. Positive lock structure
6. Compatible with a wide variety of cables
7. Mis-mating prevention with color and guide key options



EnerBee special page

EnerBee offers a positive lock mechanism to meet various requirement of industrial power supply and power sources.

Specifications

  • Connector Type
  • Contact, Socket, In-line plug
  • Parts
  • Cable Assembly
  • No
  • Industry Standard
  • Safety Standards
  • UL, C-UL/CSA, TÜV
  • Number of Positions
  • 2, 3, 4
  • Number of Rows (Interface)
  • 1, 2
  • Mounting Pitch
  • Contact Pitch
  • 3.96 mm
  • Connector Length
  • 11.66, 13.16 mm
  • Connector Width
  • 22.0, 37.96 mm
  • Connector Height
  • 10.36, 11.2, 14.76, 15.7 mm
  • Mounting Style
  • Mounting Side
  • PCB Stabilizing Feature
  • Staggered Lead
  • No
  • Recommended PCB Thickness
  • Connector Orientation
  • Straight
  • Mating/Unmating Cycles
  • 30
  • Contact Plating
  • Tin
  • Plating Thickness
  • 1.0 μm
  • Housing Color
  • Black, White
  • Wire Termination Method
  • Crimping
  • Recommended Wire Type
  • Discrete wire
  • Recommended Min. Wire Size (AWG)
  • 18, 22
  • Recommended Max. Wire Size (AWG)
  • 16, 20
  • Recommended Min. Wire Size (mm²)
  • 22.0 mm²
  • Recommended Max. Wire Size (mm²)
  • Operating Temperature Max.
  • 105 ℃
  • Operating Temperature Min.
  • -40 ℃
  • Panel Mounting Style

In cases where the application will demand a high level of reliability, such as automotive, please contact a company representative for further information.
