Shielded Small Waterproof Connector


Features

Shielded Small Waterproof Connector

1. Small, Robust Design
2. Bayonet Lock
3. Waterproof : IP67/IP68* Compliant
4. Easy Shielding Termination
5. Easy Assembly
6. Wide Variety of Configurations
7. High Speed Transmission
8. Safety Standard Certified
9. RoHS2 Compliant





LF series - Shielded Small Waterproof Connector -

Rugged & space-saving metal shell connecters sealed to IP67&68 for water-proof
are designed to withstand harsh industrial environments.

Specifications

  • Connector Type
  • Plug, Receptacle, Jack, Accessory
  • Parts
  • Flange, Cap
  • Generic Type
  • Industry Standard
  • Safety Standards
  • UL, C-UL/CSA, TÜV
  • Performance Characteristics
  • CAT5e
  • Rated Current
  • 2.0, 4.0, 5.0, 10.0 A
  • Rated Voltage (AC)
  • AC 30.0, 60.0, 125.0 V
  • Rated Voltage (DC)
  • DC 42.0, 60.0, 125.0, 175.0 V
  • Number of Positions
  • 3, 4, 6, 11, 12, 20
  • Remarks on Number of Positions
  • Operating Temperature Max.
  • 85 ℃
  • Operating Temperature Min.
  • -25 ℃
  • Water Resistance
  • IP 68
  • Contact Resistance
  • Withstanding Voltage
  • 300, 1250 V Max.
  • Locking Style
  • Friction, Screw, Bayonet
  • Wire Termination Method
  • Soldering, Crimping
  • Cable Outer Diameter
  • 5.0, 5.3, 7.3, 7.6, 8.7, 9.0 mm
  • Mating/Unmating Cycles
  • 100, 1000
  • Finger Protection
  • No
  • Metal Shields
  • No, Yes
  • Mounting Style
  • THT
  • Contact Plating
  • Gold
  • Salt Spray Test Duration (Corrosion Resistance)
  • 48, 500 h
  • Shell Material
  • Metal
  • Finish on Shell
  • Nickel, Chrome


In cases where the application will demand a high level of reliability, such as automotive, please contact a company representative for further information.
