DF22 Series
[EnerBee™] 7.92mm Contact Pitch High-Current Connectors for Internal Power Supplies (UL, C-UL and TÜV Listed)
Features
[EnerBee™]
7.92mm Contact Pitch High Current Connectors for Internal Power Supplies (UL, C-UL and TÜV Listed)
1. Rated up to 30A
2. Positive Locking Function
3. Prevention of Incorrect Connections
4. Molded-in contact retention tabs
5. Prevention of incorrect board placement
6. Supports resin sealing
7. Prevention of Short Circuits between Adjacent Contacts
8. Increased Retention Force of Crimped Contacts
9. Full Line of Crimp Socket Contacts
10. In-line Connections
11. UL, C-UL, and TÜV Certified.
12. Glow Wire compliance (Compliant with IEC 60695-2-11)
Caution:
Please use a retainer to reduce the load on the Crimp socket or In-line plug connector.
Gold-plated products are standard for this product in order to support high current. Be sure to select a gold-plated product for use in an environment with temperature changes and vibration.
*Tin and Tin Copper: Scheduled to be discontinued
EnerBee special page
EnerBee offers a positive lock mechanism to meet various requirement of industrial power supply and power sources.
- Connector Type
- Header, Plug, Socket, Contact, Others
- Parts
- Retainer
- Cable Assembly
- No
- Industry Standard
- Safety Standards
- UL, C-UL/CSA, TÜV
- Number of Positions
- 1, 2, 3, 4, 5
- Rated Current
- 15.0, 20.0, 22.0, 25.0, 30.0 A
- Rated Current other
- Rated Voltage (AC)
- AC 1000.0 V
- Rated Voltage (AC) other
- Rated Voltage (DC)
- DC 1000.0 V
- Rated Voltage (DC) other
- Number of Rows (Interface)
- 1, 2
- Mounting Pitch
- 7.92 mm
- Contact Pitch
- 7.92 mm
- Connector Length
- 8.0, 9.3, 10.8, 15.3, 15.5, 17.22, 18.0, 19.8, 23.22, 23.42, 25.14, 26.0, 27.72, 31.14, 31.34, 33.06, 35.64, 39.26, 40.98, 43.56 mm
- Connector Width
- 12.45, 23.0, 24.0, 34.95 mm
- Connector Height
- 11.55, 12.2, 12.72, 12.75, 18.1, 20.14, 21.79 mm
- Mounting Style
- THT
- Mounting Side
- Standard on-Board
- PCB Stabilizing Feature
- Soldering
- Staggered Lead
- No
- Recommended PCB Thickness
- 1.6 ｍｍ Max.
- Connector Orientation
- Straight, Right angle
- Mating/Unmating Cycles
- 30
- Contact Plating
- Gold
- Plating Thickness
- Housing Color
- Red, Black, Beige
- Wire Termination Method
- Crimping
- Recommended Wire Type
- Discrete wire
- Recommended Min. Wire Size (AWG)
- 12, 16
- Recommended Max. Wire Size (AWG)
- 10, 14, 16
- Recommended Min. Wire Size (mm²)
- Recommended Max. Wire Size (mm²)
- Applicable FPC Cable Thickness (mm)
- Operating Temperature Max.
- 85 ℃
- Operating Temperature Min.
- -55 ℃
- Panel Mounting Style
- Snap-in
- Mounting direction
- Floating Range(XY)(mm)
- Effective Mating Length(Z)(mm)
- Connector Type Details
- In-line plug, Accessory
List of Connectors (Specification Sheet, 2D drawings, 3D models, Distributor inventory)
Document
In cases where the application will demand a high level of reliability, such as automotive, please contact a company representative for further information.
