DF50 Series

Features

[SignalBee]
1mm Pitch, Board to Wire Lock Connector

1. It provides clear tactile click and secure mating
2. Robust structure resistant to wrenching forces
3. Robust and reliable lance structure
4. Ensured adsorption area eliminates the need for adsorption cap.
5. Insulation outer diameter 0.9mm dia., compatible with AWG#28

SignalBee special page

SignalBee, a sister brand to our power cable brand EnerBee, is your solution for signal cable connector.

Specifications

Connector Type Contact, Socket, Header, Others
Number of Positions 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 20, 30, 40, 50
Number of Rows (Interface) 1, 2
Mounting Pitch 1 mm
Contact Pitch 1 mm
Rated Current 0.9, 1 A
Rated Voltage (AC) AC 100 V
Rated Voltage (DC) DC 100 V
Mating/Unmating Cycles 30
Mounting Style SMT
Connector Orientation Straight, Right angle
Mounting Side Standard on-Board
Contact Plating Gold
Wire Termination Method Crimping
Recommended Wire Type Discrete wire
Recommended Min. Wire Size (AWG) AWG 26, 30, 32
Recommended Max. Wire Size (AWG) AWG 26, 28, 30
Operating Temperature (Max.) 85 ℃
Operating Temperature (Min.) -35 ℃
Glow Wire Compliant No
Catalog Product Series Catalog DOWNLOAD
Assembly Information Cable Assembly Instruction DOWNLOAD
