DF60 Series

Features

EnerBee;
65A 10.16mm pitch Wire-to-Board Connectors for Internal Power Supply

1. High current capacity
2. Secure lock mechanism ensures complete mating
3. Highly reliable 5-point contact structure
4. Molded lance design
5. Mis-insertion prevention for headers
6. Prevention of solder cracks
7. Design Prevents short-circuits between contacts
8. Compliant to UL, C-UL and TÜV specifications
9. Glow Wire compliance(Compliant with IEC 60695-2-11)
10. Finger-safe (Electric shock prevention) type available

EnerBee special page

EnerBee offers a positive lock mechanism to meet various requirement of industrial power supply and power sources.

Specifications

Connector Type Contact, Socket, Header, In-line plug
Cable Assembly No
Safety Standards UL, C-UL/CSA, TÜV
Number of Positions 1, 2, 3, 4, 5, 6
Number of Rows (Interface) 1
Mounting Pitch 10.16 mm
Contact Pitch 10.16 mm
Rated Current 38, 40, 45, 50, 55, 65 A
Rated Voltage (AC) AC 1000 V
Rated Voltage (DC) DC 1000 V
Mating/Unmating Cycles 30
Mounting Style THT
Connector Orientation Straight, Right angle
Mounting Side Standard on-Board
Panel Mounting Style Screw
Contact Plating Gold
Wire Termination Method Crimping
Recommended Wire Type Discrete wire
Recommended Min. Wire Size (AWG) AWG 8, 12
Recommended Max. Wire Size (AWG) AWG 8, 10
Operating Temperature (Max.) 105 ℃
Operating Temperature (Min.) -55 ℃
Glow Wire Compliant Yes
