2.92mm Series
2.92mm Coaxial Connectors Based On MIL Specifications
Features
2.92mm coaxial connectors MIL Standard Compliant
Compatible with 40GHz confi gurations
1. Compliant MIL-STD-348B Standard
2. Supports up to 40GHz frequency
3. Screw mounting
4. Flexible PCB thickness
5. 0.085 inch flexible cable applicable
6. RoHS2 compliant
Compatible with 40GHz confi gurations
1. Compliant MIL-STD-348B Standard
2. Supports up to 40GHz frequency
3. Screw mounting
4. Flexible PCB thickness
5. 0.085 inch flexible cable applicable
6. RoHS2 compliant
 |
Specifications
FUNCTION CHART
- Connector Type
- Receptacle, Adapter
- Parts
- Generic Type
- 2.92mm
- Industry Standard
- Water Resistance
- Cable Assembly
- No
- Cable Length
- Characteristic Impedance
- 50.0 Ω
- Frequency (Max.)
- 40.0 GHz
- V.S.W.R.
- 1.2 Max.
- Number of Positions
- 1
- Mating/Unmating Cycles
- 500, 1000
- Mounting Style
- Screw-fix
- Connector Orientation
- Straight, Right angle
- Center Contact Plating
- Gold
- Outer Contact Plating
- Passivate
- Recommended Coaxial Cable
- Cable Outer Diameter
- Wire TerMin.ation Method
- Max. Wire Insulation Diameter
- Min. Wire Insulation Diameter
- Shield Diameter
- Center Conductor Diameter
- 1.27 ｍｍ
- Notes on Recommended Wire
- Operating Temperature Max.
- 105, 125 ℃
- Operating Temperature Min.
- -55 ℃
- Cable Color
- Type 1 Mating Face Connector
- Type 2 Mating Face Connector
- Return Loss
Document
In cases where the application will demand a high level of reliability, such as automotive, please contact a company representative for further information.
