All ProductsDF13

Features

1.25mm Pitch Miniature Crimping Connector (UL Listed)

1. Miniature Size
2. Multi-contact
3. Correspond to Automatic Mounting
4. Integral Basic Function Despite Miniature Size
5. UL Certifled
6. Glow wire compliance (Compliant with IEC 60695-2-11)

Specifications

Connector Type Contact, Socket, Header, Others
Cable Assembly No, Yes
Industry Standard JIS, IEC
Safety Standards UL
Number of Positions 2, 10, 11, 12, 13, 14, 15, 20, 30, 3, 40, 4, 5, 6, 7, 8, 9
Number of Rows (Interface) 1, 2
Mounting Pitch 1.25 mm
Contact Pitch 1.25 mm
Rated Current 1 A
Rated Voltage (AC) AC 150 V
Mating/Unmating Cycles 30, 50
Mounting Style SMT, THT
Connector Orientation Straight, Right angle
Mounting Side Standard on-Board
Contact Plating Gold, Tin, Tin-Copper
Wire Termination Method Crimping
Recommended Wire Type Discrete wire
Recommended Min. Wire Size (AWG) AWG 32, 30
Recommended Max. Wire Size (AWG) AWG 26, 30
Operating Temperature (Max.) 85 ℃
Operating Temperature (Min.) -35 ℃
Glow Wire Compliant Yes
Catalog Product Series Catalog DOWNLOAD
Assembly Information Product Guidelines
DOWNLOAD
