All ProductsMS-180

Features

Subminiature Coaxial Switch 0.85 mm High, DC to 11 GHz

1. Performs over a wide frequency range
Applicable frequencies range over a wide bandwidth, from DC to 11GHz.

2. Low insertion loss
0.1 dB Max. up to 3GHz (not mated with the probe).
0.2 dB Max. up to 6GHz (not mated with the probe).
0.3 dB Max. up to 11GHz (not mated with the probe).

3. Space-saving and low profile design
0.85mm high above the board.
1.8mm x 1.8mm board space occupation.

4. Minimized Keep Out area and inspection port on chassis
Thanks to thinner probing tip in 2.24mm outer
diameter, customer are able to achieve better space saving design.

5. Automatic board placement
Packaged on tape-and-reel the receptacles can be placed with vacuum nozzles of the automatic placement equipment.

6. Beryllium Free, Halogen Free
Chlorine, and Bromine are not used in the receptacles.
Definition according to IEC 61249-2-21.

Specifications

Connector Type Plug, Receptacle
Generic Type SMA
Cable Assembly No
Characteristic Impedance 50 Ω
Frequency (Max.) 11, 8 GHz
Mating/Unmating Cycles 100, 10000
Mounting Style SMT
Connector Orientation Straight
Center Contact Plating Gold
Outer Contact Plating Gold, Nickel
Catalog Product Series Catalog DOWNLOAD

*I need help with a product or information

Products

Connector Type

Frequency (Max.)   DC GHz
Characteristic Impedance

Ω

Locking Style

Recommended Coaxial Cable


Generic Type

Connector Orientation

Cable Length   mm

Mounting Style

Panel Mounting Style
Outer Contact Plating

PCB Stabilizing Feature

Water Resistance IP

or above

Mating/Unmating Cycles   times or above



Part No.

Drawing

Connector Type

Frequency (Max.)

Characteristic Impedance

Locking Style

Recommended Coaxial Cable

Generic Type

Connector Orientation

Cable Length

Mounting Style

Panel Mounting Style

Outer Contact Plating

PCB Stabilizing Feature

Water Resistance

Connector Height

Mating/Unmating Cycles

Recommended PCB Thickness

Receptacle
11 GHz
50 Ω
Push-on
Straight
SMT
Nickel
100
Plug
8 GHz
50 Ω
Straight
Gold
10000
Plug
8 GHz
50 Ω
Straight
Gold
10000
Plug
8 GHz
50 Ω
Straight
Gold
10000
Plug
50 Ω
SMA
Straight
Gold
